GU Europa 92mm centred door locking mechanism

There are 2 versions of this particular lock:

• on one style you would lift the handle to engage the mechanism (Lift Lever)
• on the other you would turn the key to engage the mechanism (Key-wind)


Lift lever     £58.00                         Key-wind       £92.00

GU Europa details

• Centre: 92mm
• Backset: 28mm or 35mm
• 4 rollers - 1610mm between the top and bottom rollers

• 1 Latch
• 1 deadbolt
• Styles: Lift lever or Key-wind


Measurement A is the Centre.This is the distance between the centre of the barrel and the center of the spindle.

Measurement B is the back set. That is the distance from the front of the locking system to the middle of the spindle.
